604

18.2 SELECTION DATA

18.2.1 Specifications

Model FDF508HES-SB

Item

Model

FDF508H FDC508HES3B

Nominal cooling capacity

(1)

W 12500

Nominal heating capacity

(1)

W 14000

Power source 3 Phase, 380V, 50Hz

Cooling input kW 5.42

Running current (Cooling) A 9.8

Power factor (Cooling) % 84

Heating input kW 4.97

Running current (Heating) A 9.3

Power factor (Heating) % 81

Inrush current (L.R.A) A 74

Noise level

(4)

dB(A) Hi: 49 Lo: 45 55

Exterior dimensions

mm 1850 × 600 × 350 1250 × 920 × 340

Height × Width × Depth

Net weight kg 46 101

Refrigerant equipment

— GU-A5570ES41 × 1

Compressor type & Q’ty

Motor kW — 3.75

Starting method — Line starting

Heat exchanger Louver fines & inner grooved tubing Slitted fines & bare tubing

Refrigerant control Capillary tube

Refrigerant R22

Quantity kg —

1.9

[Pre-charged up to the piping length of 5m]

Refrigarant oil r — 1.6 (BARREL FREEZE 32SAM)

Defrost control IC controlled de-icer

High pressure control High pressure switch

Air handling equipment

Sirocco fan × 1 Propeller fan × 2

Fan type & Q’ty

Moter W 130 × 165 × 2

Starting method Line starting Line starting

Air flow (Standard) CMM Hi: 28 Lo: 23 110

Fresh air intake Unavailable —

Air filter, Q’ty Polypropylene net (washable) —

Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)

Electric heater W — 40 (Crank case heater)

Operation control

Operation switch Control switch – (Indoor unit side)

Electric heater — (Can be incorporated: PTC Heater 2.2 kW) —

Room temperature control Thermostat by electronics —

Safety equipment

Installation data mm

Liquid line: φ9.52 (3/8″) Gas line: φ19.05 (3/4″)

Refrigerant piping size (in)

Connecting method Flare piping

Drain hose (Connectable with VP20) —

Insulation for piping Neccessary (both Liquid & Gas lines)

Accessories Mounting kit.

Optional parts Electric heater

Operation data

(3)

Internal thermostat for fan motor.

Abnormal discharge temperature protection.

(2) This packaged air conditioner is manufactured and tested in conformity with the following standard. ISO-T1 "UNITARY AIR CONDITIONERS"

(3) The operation data indicate when the air-conditioner is operated at 380V 50Hz.

(4) Indicators the value at mild mode.

Notes (1) The data are measured at the following conditions.

Item Indoor air temperature Outdoor air temperature

Standards

Operation DB WB DB WB

Cooling 27˚C 19˚C 35˚C 24˚C

Heating 20˚C — 7˚C 6˚C

ISO-T1 JIS B8616

Internal thermostat for fan motor

Frost protection thermostat.

FDF508HES-SB
